Tekmar Three Outdoor Sensor Module
081
Tekmar Three Outdoor Sensor Module
Tekmar Three Outdoor Sensor Module
Details
Specifications
| Dimensions | 2-1/8" H x 9/16" W x 9/16" D (54 x 14 x 14 mm) |
| Operating Range | -60 to 140 degrees F (-51 to 60 degrees C) |
| Sensor | NTC thermistor, 10 k ohms at 77 degrees F (25 degrees C plus / minus 0.2 degrees C) Beta = 3892 |
Description
The Three Outdoor Sensor Module 081 includes three 10 k ohm thermistors which provides an accurate measurement of the outdoor temperature. Each sensor has two separate terminals for wiring. The 081 is designed to be installed in a tekmar Outdoor Sensor 070 enclosure. This allows for four separate sensors to be combined into a single enclosure that is mounted on the exterior of the building.
Features
Provides outdoor temperature readings for multiple controls in one enclosure
Each sensor has two separate terminals for wiring
Allows for four separate sensors to be combined into a single enclosure
Mounted on the exterior of the building
Tekmar 081 Submittal
