009
Tekmar 24 V (ac) Transformer
40 VA, 24 V (ac) Transformer
The Transformer 009 is a 40 VA, 24 V (ac) transformer for use with products that require an external transformer. It includes an in-line fuse for circuit protection.
Features
- 24 V (ac), 40 VA transformer
- Replaceable in-line fuse included
| Approvals | CSA standard C22.2 #66 part B & UL 5085 |
| Ambient conditions | Indoor use only, 32 to 221°F (0 to 105°C) |
| Input power supply | 120 V (ac) ± 10%, 60 Hz |
| Output power available | 24 V (ac) ± 10% 60 Hz, 1.67A, 40 VA, Class 2 |
| Supplied fuse rating | 250 V (ac), 2.0 A |
| Warranty | Limited 3 Year Warranty |
